Side Tilt Carriage - Rated by the tine carriage hoisting capacity, there are actually four sizes of hook type tine carriages. The hook type fork carriages have been standardized.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing for Class I is thirteen inches. Class II carriages are rated for cargo as much as 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing utilized for this capacity is 25 inches.
The carriages for pin type blades may be different depending on the manufacturer. Pin mounted blades may vary by the amount of offset between the fork eye and the blade. Carriage capacity will be determined by the carriage pin size and by the fork size.
